Product highlights

• 2×2 MU-MIMO 802.11ac Wave 2
• 1.3 Gbps* aggregate dual-band frame rate
• Integrated enterprise security and guest access
• Built-in WIPS for threat detection and remediation
• Application-aware traffic shaping
• Self-configuring, plug-and-play deployment
• Rapid, plug-and-play deployment
• Integrated location analytics and heat map

Specifications

Radios management

2.4 GHz 802.11b/g/n/ac client access radio
5 GHz 802.11a/n/ac Wave 2 client access radio
Supported frequency bands (country-specific restrictions apply):
2.412-2.484 GHz
5.150-5.250 GHz (UNII-1)
5.250-5.350 GHZ (UNII-2)
5.470-5.600, 5.660-5.725 GHz (UNII-2e)
5.725-5.825 GHz (UNII-3)

802.11ac and 802.11n capabilities

2 x 2 multiple input, multiple output (MIMO) with two spatial streams
SU-MIMO and MU-MIMO support
Maximal ratio combining (MRC) & Beamforming
20 and 40 MHz channels (2.4 GHz), 20, 40, and 80 MHz
channels (5 GHz)
Up to 256-QAM on both 2.4 GHz and 5 GHz bands

Antenna

Integrated omni-directional antennas
(4.5 dBi gain at 2.4 GHz, 4.7 dBi gain at 5 GHz)

Power

Power over Ethernet: 37-57 V (802.3af compatible)
Power consumption: 11 W max (802.3af)
Alternative 12 V DC input
Power over Ethernet injector sold separately

Interfaces

1x 100/1000 BASE-T Ethernet (RJ45)

Mounting

Mounts to walls and vertical poles
Mounting hardware included
Physical security
Security screw included

Physical security

Security screw included

Environment

Operating temperature: -4 °F to 131 °F (-20 °C to 55 °C)
IP67 environmental rating
Operating Altitude: Up to 40,000 feet (12,192 meters)
Operating humidity: 5% to 95%

Physical dimensions

9.65” x 4.53” x 1.18” (245 mm x 115 mm x 30 mm)
Weight: 15.87 oz (0.45 kg)
