• LED indicators for the audio path keys
• LED indicators for select key, line keys, and message waiting.
• Four soft key buttons and a scroll toggle bar
• Two line key buttons
• Two-way navigation and select keys
• Wideband audio
• Dual-position foot stand
• Greyscale Graphical display 396 x 162 pixel-based with white backlight
• RJ9 interface to optional headset
• Ethernet switch
• PoE class 1
• Supported Protocols: Session Initiation Protocol (SIP)
• Wall-mountable

Specifications

Product Name: 7832 Conference Phone for MPP
Manufacturer Part Number: CP-7832-3PCC-K9

Dimensions & Weight (Base)

Depth: 2.8 cm
Height: 20.7 cm
Weight: 867 g
Width: 20.6 cm

Display

Backlit: Yes
Diagonal Size: 3.5″
Display Languages: Danish, Hebrew, Hungarian, Czech, Croatian, Slovenian, Thai, Slovak, Brazilian Portuguese, English, German, French, Italian, Norwegian, Portuguese, Polish, Finnish, Swedish, Russian, Spanish, Dutch, Greek, Turkish, Arabic, Bulgarian, Latvian, Lithuanian, Estonian, Serbian, Romanian, Catalan, Japanese, Chinese, Korean
Display Location: Base
Display Resolution: 396 x 162 pixels
Type: LCD display – monochrome

General

Body Material: PC/ABS
Product Type: VoIP phone

IP Telephony

IP Address Assignment: DHCP, static
Lines Supported: 2 lines
Main Features: Multiple VoIP protocol support, integrated Ethernet switch
Network Features: Lightweight Directory Access Protocol (LDAP)
Network Ports Qty: 2 x Ethernet 10Base-T/100Base-TX
Network Protocols: Cisco Discovery Protocol (CDP), SRTP
Power Over Ethernet (PoE) Support: Yes
Quality of Service: IEEE 802.1Q (VLAN), IEEE 802.1p
Security: IEEE 802.1X
VoIP: Yes
VoIP Protocols: SIP, SRTP
Voice Codecs: G.722, G.729ab, G.711u, G.711a, iLBC

Miscellaneous

Compliant Standards: CISPR 22 Class B, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, ICES-003 Class B, AS/ACIF S004, FCC Part 68, EMC, CS-03, UL 60950-1 Second Edition, EN 60601-1-2, FCC CFR47 Part 15 B, GB 4943, AS/NZS 60950, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class B
Connections: Headset jack
Placing / Mounting: Wall-mountable, table-top

Phone Features

Additional Features: Music on hold
Additional Functions: Call timer
Call Services: Voice Mail, Caller ID, Call Waiting, Call Forwarding, Call Transfer, Call Hold, Message Waiting Capability
Conference Call Capability: Yes
Dialer Location: Base
Dialer Type: Keypad
Firmware Upgradable: Yes
Indicators: Voice message waiting indicator, speakerphone indicator, headset
Menu Operation: Yes
Programmable Buttons Qty: 2
Speakerphone: Yes (digital duplex)
