Specifications

Design
Rack mounting: Y
Product colour: Silver
LED indicators: Y

Management features
Switch type: Managed
Switch layer: L2/L3
Quality of Service (QoS) support: Y
Web-based management: Y
ARP inspection: Y
Configuring Location Settings (CLI): Y
MIB support: Y

Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity: 4

Data transmission
MAC address table: 16000 entries
Jumbo frames support: Y
Jumbo frames: 9000

Protocols
Management protocols: SNMP

Network
Networking standards: IEEE 802.1D,IEEE 802.1w,IEEE 802.1s,IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3ad
10G support: Y
Port mirroring: Y
Flow control support: Y
Link aggregation: Y
Broadcast storm control: Y
Auto MDI/MDI-X: Y
Spanning tree protocol: Y
Head-of-line (HOL) blocking: Y
Ethernet LAN data rates: 10,100,1000 Mbit/s
VLAN support: Y
Number of VLANs:4094

Power
Power supply included: Y

Multicast features
Multicast support: Y

Security
Access Control List (ACL): Y
Access Control List (ACL) rules: 1024
IGMP snooping: Y
MAC address filtering: Y
SSH/SSL support: Y

Operational conditions
Operating temperature (T-T): -5 – 50 °C
Storage temperature (T-T): -25 – 70 °C
Operating relative humidity (H-H): 10 – 90 %
Storage relative humidity (H-H): 10 – 90 %
