Specifications

Interfaces
Ports: 16 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+
2 x 10/100/1000 Mb/s Gigabit SFP
1 x USB Type-A (Console)

Protocols
Layer Services Supported: Layer 2 Support, Layer 3 Support
Supported Protocols:
Head-of-Line (HOL) Blocking
IGMP Snooping
IPv4
IPv6
Link Aggregation
MAC Filtering
Port Mirroring
RADIUS
SNMPv1
SNMPv2c
SNMPv3
Queuing Strict Priority: Weighted Round Robin (WRR)
Jumbo Frames Support: 9000 Bytes
MAC Address Table Size: 8K
Multicast Groups :255
VLAN IDs: 255

Security
Security Features: DoS Attack Prevention, RADIUS Authentication, Storm Control
Access Control List: 512
IP Interfaces: 16
Static Routes :32
SNMP Support :1, 2c, 3

Standards
RFC: RFC 4330
Supported IEEE Standards: 802.1d, 802.1q, 802.1q/p, 802.1s, 802.1w, 802.1x, 802.3, 802.3ad, 802.3af, 802.3at, 802.3u, 802.3x, 802.3z

Performance
Forwarding Rate: 26.78 Mpps
Switching Bandwidth: 36 Gb/s
Priority Queues: 8
Packet Buffer: 1.5 MB

Computer
Flash Memory: 256 MB
Processor: 800 MHz ARM
Memory: 512 MB

Electrical
Power Draw: 156.4 W (Max)
AC Input Power: 100 to 240 VAC, 50 / 60 Hz
PoE Power Budget: 120 W
PoE per Port: 30 W
Power Supply Type: Internal

Environmental
Operating Temperature: 23 to 122°F / -5 to 50°C
Operating Humidity: 10 to 90%
Storage Temperature: -13 to 158°F / -25 to 70°C
Storage Humidity: 10 to 90%

General
Cooling System: Passive
Mean Time Between Failures (MTBF): 706,983 Hours
Indicator Lights: Link/Activity, PoE, Speed, System
Rack Form Factor: 1 RU
Dimensions: 10.7 x 10.6 x 1.7″ / 272 x 268 x 44 mm
Weight: 5.25 lb / 2.38 kg
