PTP 550 is a Point to Point Gigabit throughput solution based on 802.11ac Wave 2 operating in 5 GHz wireless space, addressing the gigabit capacity needs for high speed backhaul solutions in short range and middle range applications provides up to 1.36 Gbps throughput with ARQ and asymmetric non-contiguous channel aggregation across 5 GHz band. The PTP 550 solution draws its attributes from Cambium Networks’ Point to Point products such as PTP 650/670 and PTP 450i. Each PTP 550 radio is enclosed in a rugged IP66/67 rated metal enclosure, which protects the radio from extreme conditions and solar radiation.
Cambium PTP 550 6 GHz Unlicensed Band Solution featuring DCS & AES in Dubai UAE
SKU: Cambium PTP 550 6 GHz
Categories: Cambium Networks
Support from Our Knowledge Hub
Ask us anything!
- 8/5 Online
Tel: +971 4352 24 33
Description
RADIO TECHNOLOGY
RF BANDS
Wide-band operation 5.170 to 5.980 GHz (Allowable frequencies and bands are dictated by individual country regulations)
CHANNEL SIZES
Dual independent channels, each channel configurable as 20, 40 & 80 MHz
SPECTRAL EFFICIENCY
8.5 bps/Hz maximum
CHANNEL SELECTION
Fixed frequency or Dynamic Channel Selection (DCS)*
ETHERNET BRIDGING
PROTOCOL
IEEE 802.3
LATENCY
1-3 milliseconds one direction
PACKET CLASSIFICATION
Layer 2 and Layer 3 IEEE 802.1p, Ethernet priority
MANAGEMENT
NETWORK MANAGEMENT
T In-band management
SYSTEM MANAGEMENT
IPv6/IPv4 dual-stack management support SNMPv2c, https, WPA2-PSK Online spectrum analyzer (no impact on payload traffic)
PHYSICAL
DIMENSIONS
Integrated Outdoor Unit (ODU): Width 305mm (12”), Height 305mm (12”), Depth 56mm (2.2″) Connectorized Outdoor Unit (ODU): Width 177mm (7”), Height 280mm (11”), Depth 89mm (3.5”)
WEIGHT
Integrated Outdoor Unit (ODU): 2.2 kg (4.85 lbs) including bracket Connectorized Outdoor Unit (ODU): 1.6 kg (3.5 lbs) including bracket
DUST- WATER INTRUSION PROTECTION
IP66 and IP67
Additional information
| Brand | Cambium Networks |
|---|
Be the first to review “Cambium PTP 550 6 GHz Unlicensed Band Solution featuring DCS & AES in Dubai UAE” Cancel reply
RADIO TECHNOLOGY
RF BANDS
Wide-band operation 5.170 to 5.980 GHz (Allowable frequencies and bands are dictated by individual country regulations)
CHANNEL SIZES
Dual independent channels, each channel configurable as 20, 40 & 80 MHz
SPECTRAL EFFICIENCY
8.5 bps/Hz maximum
CHANNEL SELECTION
Fixed frequency or Dynamic Channel Selection (DCS)*
ETHERNET BRIDGING
PROTOCOL
IEEE 802.3
LATENCY
1-3 milliseconds one direction
PACKET CLASSIFICATION
Layer 2 and Layer 3 IEEE 802.1p, Ethernet priority
MANAGEMENT
NETWORK MANAGEMENT
T In-band management
SYSTEM MANAGEMENT
IPv6/IPv4 dual-stack management support SNMPv2c, https, WPA2-PSK Online spectrum analyzer (no impact on payload traffic)
PHYSICAL
DIMENSIONS
Integrated Outdoor Unit (ODU): Width 305mm (12”), Height 305mm (12”), Depth 56mm (2.2″) Connectorized Outdoor Unit (ODU): Width 177mm (7”), Height 280mm (11”), Depth 89mm (3.5”)
WEIGHT
Integrated Outdoor Unit (ODU): 2.2 kg (4.85 lbs) including bracket Connectorized Outdoor Unit (ODU): 1.6 kg (3.5 lbs) including bracket
DUST- WATER INTRUSION PROTECTION
IP66 and IP67
