Description
SPECTRUM
Channel Spacing
Configurable in 5 MHz increments
Frequency Range
Wide Band Operation 5.150 – 5.970 MHz (Note: Allowable frequencies and bands are dictated by individual country regulations.)
Channel Width
20 | 40 | 80 MHz
INTERFACE
Proprietary Physical Layer
2×2 MIMO/OFDM
Ethernet Interfaced
10/100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts
Protocols Used
IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
PERFORMANCE
Nominal Receive Sensitivity (w/FEC) @20 MHz Channe
MCS0 = -87 dBm to MCS8 (256 QAM-3/4) = -63 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @40 MHz Channel
MCS0 = -85 dBm to MCS9 (256QAM-5/6) = -59 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @80 MHz Channel
MCS0 = -82 dBm to MCS9 (256QAM-5/6) = -56 dBm (per chain)
PHYSICAL
Environmental
IP55
Temperature
-22°F to +140°F (-30°C to +60°C)
Weight
2.4 kg (5.3 lbs)
Dimensions (Dia x Depth)
47 cm x 31 cm (18.5 in x 12.2 in)
SECURITY
Encryption
128-bit AES (CCMP mode)
