ACCESS POINT SPECIFICATIONS
Frequency Bands
2.4 GHz: 2.4 – 2.4835 GHz Channels 1 – 13 (ETSI/CE), Channels 1 – 11 (US) 5 GHz: 5.15 – 5.85 GHz
SSID Security
WPA-2 (802.11i): WPA2-Enterprise (802.1x/EAP) & WPA2-Preshared-keys, Open
Max SSIDs
16
Max Concurrent Clients
512
Max Data Rates
2.4GHz: 400Mbps, 5GHz: 1733Mbps
Ethernet Ports
Dual Gigabit Ethernet ports (2 x 10/100/1000Base-T)
Antenna
Integrated Omni
Antenna Gain
8 dBi (2.4 GHz and 5 GHz)
Power Consumed
Typical 18W. Max 24.6W
Dimensions (cm)
315 x 215 x 66 mm (without bracket)
Weight
3.174 lbs (1700 gms) without bracket
WI-FI FEATURES
Controller modes
• Autonomous Controller-less operations (E.g.: roaming) • Cloud Managed • On-premise virtualized controller
Secure WLAN
WPA-TKIP, WPA2 AES, 802.1x 802.11w (Protected Management Frames)
Hotspot 2.0
Passpoint supported
Captive Portal
• cnMaestro Controller • Redirection to external RADIUS •Stand-alone AP based • Server DNS logging
Authentication
• RADIUS based 802.1x including EAP-SIM/AKA, EAP-PEAP, EAP-TTLS, and EAP-TLS • MAC auth (local database or External RADIUS server)
Scheduled SSID
Turn SSID ON/OFF on a daily/weekly/time of day basis
Guest Access
Yes. With Active Directory Integration • Vouchers • Rate limiting • Splash page creation on cnMaestro
cnMAESTRO WI-FI CONTROLLER
Common Manager
Single pane of glass: Controller for Wi-Fi and network manager for ePMP and PMP wireless backhaul products
On-Boarding
Secure zero touch fast on-boarding
Provisioning
Easy zero touch virtual network provisioning Provision before install (pre-provision)
Device Inventory
Inventory tracking
Configuration
GUI based configuration or template based configuration options
