Description
Features
- Powerful multilevel-access security controls include source-port filtering, RADIUS/TACACS+, SSL, Port Security, and MAC address lockout.
- Supports both cloud-based Central and on-premise AirWave with the same hardware ensuring change of management platform without ripping and replacing switching infrastructure.
- Robust Layer 2 features include static and RIP routing, ACLs, sFlow, IPv6 with no software licensing required.
- Built-in programmable and easy to use REST API interface provides configuration automation for Mobile-first campus networks.
- RMON and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms and events.
- The Aruba 2540 Switch Series supports Aruba ClearPass Policy Manager for unified and consistent policy management between wired and wireless users and simplifies implementation and management of guest login, user onboarding, network access, security, QoS, and other network policies.
- The Aruba 2540 Switch Series includes security and quality of services features to build a network that meets ever-changing corporate policies and compliance requirements while protecting your data from both inside and outside threats.
- Built-in 10GbE uplinks reduce congestion to aggregation/core switches.
- Supports up to 370 W of internal PoE+ power across all access ports for wireless APs, cameras and IoT devices.
- Increase performance with selectable queue configurations and associated memory buffering that meets your specific network application requirements.
- The Aruba 2540 Switch Series is designed with a powerful Aruba ProVision ASIC with low latency, increased packet buffering, and adaptive power consumption.
- The Aruba 2540 Switch Series delivers entry level access switch features for the enterprise campus, SMB and branch offices. It is simple to deploy and manage with Aruba AirWave, Aruba ClearPass Policy Manager and cloud-based Aruba Central.
- Provides optimal configuration automatically when connected to Aruba access points for PoE priority, VLAN configuration, and rogue AP containment.
- Zero Touch Provisioning provides quick and painless deployment at locations with few or no technical resources.
- Convenient built-in wire speed 10GbE uplinks and PoE+ models deliver outstanding network access performance.
- Flexible authentication options include standards-based security protocols such as 802.1X, MAC and Web Authentication, to enhance security and policy-driven application authentication.
- Supports Aruba AirWave and Aruba Central to provide a common platform for Zero Touch Provisioning management, and monitoring for wired and wireless networks.
- Network Ports : 48x 1 Gigabit Ethernet RJ-45
- Uplink Ports : 4x 10 Gigabit Ethernet SFP+
- Management Ports : 1x Dual-personality (RJ-45 or USB micro-B) Serial Console
- Fan Modules AirFlow Direction : Side to Side Airflow
- Power Supplies Included : 1x AC Internal Power Supply
- Switching Capacity : 176 Gbps
- Forwarding Rate : 112.0 Mpps
- MAC Address Table Size : 16,384
- Latency : <3.8 µs (1000MB), <1.6 µs (10Gbps)
- Rack Mounts : Included (1-RU)
- Model Number : JL355A
