Description
SUA750I Features
APC Smart-UPS 750VA USB & Serial 230V
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Includes: CD with software, Smart UPS signalling RS-232 cable, USB cable, User Manual
- Battery replacement without tools
Enables fast battery replacement, lowering Mean Time to Repair (MTTR).
- Front-access servicing
Simplifies installation and UPS maintenance while minimizing space requirements.
- USB connectivity
Provides management of the UPS via a USB port (not available on all models).
-
Smart-UPS Features & Benefits
Availability
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.Disconnected battery notification
Warns when a battery is not available to provide backup power.Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.Marketing Features
Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.Smarter productivity with ability to tailor to your specific application needs
Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds and notifications.Save time with easy and convenient remote accessibility
Network manageable via serial, USB or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown and innovative energy management capabilities.Low operating and maintenance costs with high efficiency, proven reliability and intelligent battery management
Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Dynamic battery replacement date indicator and automatic self tests insure battery reliability and warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed and manufactured by APC for over 23 years, Smart-UPS is the world’s most trusted network UPS with over 25 million units sold.Avoids costly power problems by keeping your IT equipment and data safe and available
Network grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systemsSafety
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.Adaptability
Adjustable voltage-transfer points
Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.Adjustable voltage sensitivity
Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.Serviceability
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replacedUser-replaceable batteries
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)Resettable circuit breakers
Enables a quick recovery from overload events.Predictive failure notification
Provides early-warning fault analysis ensuring proactive component replacement.Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenanceManageability
LED status indicators
Quickly understand unit and power status with visual indicators.Audible alarms
Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.Network manageable
Provides remote power management of the UPS over the network.Disconnected battery notification
Warns when a battery is not available to provide backup power.Serial connectivity
Provides management of the UPS via a serial port.USB connectivity
Provides management of the UPS via a USB port (not available on all models).Technical Specifications
Output
Output power capacity
500Watts / 750VAMax Configurable Power (Watts)
500Watts / 750VANominal Output Voltage
230VOutput Voltage Note
Configurable for 220 : 230 or 240 nominal output voltageOutput Voltage Distortion
Less than 5% at full loadOutput Frequency (sync to mains)
47 – 53 Hz for 50 Hz nominal, 57 – 63 Hz for 60 Hz nominalTopology
Line Interactive
