General
Device Type Switch – 48 ports – Managed
Enclosure Type Desktop 1U
Subtype Fast Ethernet
Ports 48 x 10/100 + 2 x 10/100/1000 + 2 x SFP
MAC Address Table Size 8K entries
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 2c, HTTP
Encryption Algorithm MD5
Authentication Method RADIUS
Features Flow control, auto-sensing per device, auto-negotiation, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, MAC address filtering, Broadcast Storm Control, wall mountable
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x
RAM 32 MB
Flash Memory 4 MB Flash
Status Indicators Port status, link activity, power, link OK
Expansion / Connectivity
Interfaces 48 x 100Base-TX – RJ-45 ¦ 1 x console – DB-9 – management ¦ 2 x 1000Base-T – RJ-45 ¦ 2 x SFP (mini-GBIC)
Power
Power Device Internal power supply
Voltage Required AC 120/230 V (50/60 Hz)
Miscellaneous
Rack Mounting Kit Included
Compliant Standards FCC Class A certified, TUV, C-Tick, EN 60950, UL 1950, VCCI Class A ITE, EN55024, EN55022 Class A
Localisation United Kingdom
Dimensions & Weight
Width 44 cm
Depth 32.2 cm
Height 4.4 cm
Weight 2.2 kg
Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 5 – 90%
