Performance
14,880pps for 10Mbps Ethernet
148,800pps for 100Mbps Ethernet
1,488,000pps for 1000Mbps Ethernet
MAC Addresses 8K
Packet Buffer 512KB
Power Characteristics
Voltage 100-240vAC
Frequency 50/60Hz
Current 0.3A
Interface Connections
10/100TX RJ-45
1000FX (SFP) 1000SX or 1000LX
1000T RJ-45
Environmental Specifications
Operating Temp.- 0°C to 40°C (32°F to 104°F)
Non-operating Temp. -25°C to 70°C (-13°F to 158°F)
Operating Humidity 5% to 90% non-condensing
Storage Humidity 5% to 95% non-condensing
Physical Characteristics
Dimensions 44.0 x 25.7 x 4.32 cm (17.3 x 10.1 x 1.7 in)
Weight 3.24 kg (7.15 lbs)
Wall-mount or Desktop
All units come with Wall & 19″ Rack mount brackets
Standards & Compliance
IEEE802.3 CSMA/CD
IEEE802.3u 100 Base Tx
IEEE802.3z 1000 Base SX
IEEE802.3z/ab 1000 Base T
IEEE802.3x Flow-Control
IEEE 802.1p Prioritization (4 queues)
IEEE802.1x Authentication
IEEE802.1d Bridging
IEEE802.3ad Link Aggregation
Electrical/Mechanical Approvals
UL 1950
FCC/EN55022 Class A
VCCI Class A
C-Tick
EN60950 (TUV)
EN55024
CE
Product Contents
Switch unit
RS232 cable
Rackmount/wall mount brackets & screws
Power Cord
User Manual/Install guide on CD
Rubber feet
